Pipe Welding Robot
PRODUCT PARAMETERS
- Product Name: Pipe Welding Robot
- Models: M77 / M130 / M180 / M230 / M320
- Weldable Materials: Carbon Steel, Stainless Steel, Alloy Steel
- Shielding Gas: Argon
- Cooling Method: Water Cooling
- Cooling Flow Rate: ≥600 ml/min
- Weaving Speed Range: 0–40 mm/s
- Max. Wire Feeding Speed: 0–6000 mm/min
Description
FAQs
Request A Quote
Description
Pipe Welding Robot
Pipe Welding Robot is designed for automatic circumferential welding of pipes. The system combines stable welding parameters with precise workpiece rotation to achieve smooth, uniform and consistent circumferential welds.
Flexible configurations are available for different pipe diameters and application requirements. By reducing manual operation, the system improves productivity and is suitable for efficient batch pipe welding applications.
Product Features
- Automatic Circumferential Welding: Automates circumferential pipe welding for higher productivity.
- Consistent Weld Quality: Maintains stable welding speed and parameters for consistent weld quality.
- Precise Rotation Control: Precise workpiece rotation enables smooth and uniform circumferential welding.
- Flexible Pipe Sizes: Flexible configuration for different pipe diameters and applications.
- Higher Productivity: Reduces manual operation and improves pipe welding productivity.
Applicable Materials
- Carbon Steel
- Stainless Steel
- Alloy Steel
Product Specifications
| Parameter | M77 | M130 | M180 | M230 | M320 |
|---|---|---|---|---|---|
| Weldable Material | Carbon Steel, Stainless Steel, Alloy Steel | Carbon Steel, Stainless Steel, Alloy Steel | Carbon Steel, Stainless Steel, Alloy Steel | Carbon Steel, Stainless Steel, Alloy Steel | Carbon Steel, Stainless Steel, Alloy Steel |
| Weldable Pipe Diameter | Φ190.5–Φ77 mm | Φ88.1–Φ130 mm | Φ50.8–Φ180 mm | Φ120–Φ330 mm | Φ150–Φ324 mm |
| Welding Wall Thickness | Φ2.4, Φ3.2 | Φ2.4, Φ3.2 | Φ2.4, Φ3.2 | Φ2.4, Φ3.2 | Φ2.4, Φ3.2 |
| Rotation Speed | 0.19–3.8 | 0.11–2.2 | 0.09–1.8 | 0.05–1.0 | 0.026–0.52 |
| Shielding Gas | Argon | Argon | Argon | Argon | Argon |
| Cooling Method | Water Cooling | Water Cooling | Water Cooling | Water Cooling | Water Cooling |
| Cooling Flow Rate | ≥600 ml/min | ≥600 ml/min | ≥600 ml/min | ≥600 ml/min | ≥600 ml/min |
| Welding Speed | 20 m/min | 40 m/min | 40 m/min | 40 m/min | 40 m/min |
| Arc Length Height | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm |
| Weaving Width Accuracy | <5% | <5% | <5% | <5% | <5% |
| Weaving Speed Range | 0–40 mm/s | 0–40 mm/s | 0–40 mm/s | 0–40 mm/s | 0–40 mm/s |
| Max. Wire Feeding Speed | 0–6000 mm/min | 0–6000 mm/min | 0–6000 mm/min | 0–6000 mm/min | 0–6000 mm/min |
| Weight | 5.5 kg (5 Without Electrode) | 10.8 kg (8 Without Electrode) | 24 kg (20 Without Electrode) | 25 kg (Without Electrode) | 36 kg (Without Electrode) |
| Overall Dimensions | 370 × 220 × 400 mm | 410 × 300 × 405 mm | 455 × 492 × 562 mm | 460 × 540 × 580 mm | 420 × 610 × 680 mm |
Wire Diameter: Based on 4 in (100 mm), 1 kg standard wire spool; wire diameter Φ1.0 (optional).
