YS-200S
PRODUCT PARAMETERS
- Product Name: YS-200S Self-Propelled Dual-Spindle Beveling Machine
- Model: YS-200S
- Plate Thickness: 6–80 mm
- Processing Angle: 0°–90° Adjustable
- Beveling Speed: 0.6–1.5 m/min
- Maximum Bevel Width: 80 mm
- Bevel Types: K / V / X / Y + Upper Bevel + 0° Side Bevel
- Main Cutting Motor: 4 kW × 2
- Clamping: Electric Automatic Plate Clamping
- Processing Method: Milling
- Customization: Available according to application requirements
Description
FAQs
Request A Quote
Description
YS-200S Self-Propelled Dual-Spindle Beveling Machine
YS-200S is a self-propelled dual-spindle beveling machine designed for high-efficiency plate edge preparation and industrial welding preparation.
The dual-spindle structure allows two bevels to be processed in one operation, significantly improving processing efficiency compared with conventional single-side beveling.
The machine supports plate thicknesses from 6 to 80 mm and adjustable processing angles from 0° to 90°. The beveling speed can be continuously adjusted from 0.6 to 1.5 m/min through variable-frequency control.
YS-200S adopts a cold milling process, helping maintain a clean bevel surface without heat-induced oxidation or deformation.
Customization is available according to plate specifications, beveling requirements and production applications.
Product Features
- Dual-Spindle Processing: Two bevels can be processed in one operation for higher production efficiency.
- Self-Propelled Operation: Designed for continuous and efficient plate beveling.
- Wide Plate Thickness Range: Suitable for 6–80 mm plate thickness.
- Adjustable Processing Angle: Processing angle can be adjusted from 0° to 90°.
- Variable Beveling Speed: 0.6–1.5 m/min with variable-frequency adjustment.
- Multiple Groove Types: Supports K / V / X / Y grooves, upper bevel and 0° side bevel.
- Large Bevel Capacity: Maximum bevel surface up to 80 mm.
- Cold Milling Process: Helps avoid oxidation and thermal deformation of the bevel surface.
- Automatic Clamping: Electric automatic plate clamping helps maintain stable clamping force.
- Electric Height Adjustment: Electric lifting combined with floating lifting adjustment.
- Customizable: Configuration can be customized according to application requirements.
Product Specifications
| Parameter | Specification |
|---|---|
| Model | YS-200S |
| Product Type | Self-Propelled Dual-Spindle Beveling Machine |
| Power Supply | 380V / 50Hz, 3-Phase AC |
| Total Motor Power | 8.99 kW |
| Main Cutting Motor Power | 4 kW × 2, 380V / 50Hz |
| Lifting Motor Power | 0.2 kW / 220V / 50Hz |
| Spindle Speed | 1500 r/min |
| Processing Angle | 0°–90°, Adjustable |
| Cutter Disc Diameter | 80 mm |
| Maximum Bevel Width | 80 mm |
| Number of Inserts | 7 Square Eight-Edge Inserts |
| Bevel Types | K / V / X / Y Groove + Upper Bevel + 0° Side Bevel |
| Height Adjustment | Electric Lifting + Floating Lifting Adjustment |
| Beveling Speed | 0.6–1.5 m/min, Variable Frequency Adjustable |
| Plate Thickness | 6–80 mm |
| Clamping Method | Electric Automatic Plate Clamping |
| Processing Method | Milling |
| Surface Roughness | Ra 3.2–6.3 |
Applicable Materials
- Carbon Steel
- Stainless Steel
- Alloy Steel
- Cast Iron
- Aluminum Plate
Applications
- Dual-side plate beveling
- Welding edge preparation
- K / V / X / Y groove preparation
- Heavy plate processing
- Steel structure fabrication
- Pressure vessel manufacturing
- Industrial metal fabrication
