CP160V Weld Seam Tracking Sensor

PRODUCT PARAMETERS

  • Model: CP160V
  • Product Type: Weld seam tracking sensor
  • Central Working Distance: 160 mm
  • Detection Range: Z-axis 80–240 mm; Y-axis 55–130 mm
  • Maximum Frame Rate: 110 Hz
  • Communication: TCP, Modbus TCP, UDP and EtherNet/IP
  • Operating Voltage and Power: 24 V; maximum 6 W
  • Operating Temperature: -10°C to 60°C
  • Dimensions and Weight: 93 × 67 × 33 mm; 323 g
  • Application: Robotic seam positioning and real-time tracking
Description
FAQs
Request A Quote

Description

CP160V Weld Seam Tracking Sensor

The CP160V Weld Seam Tracking Sensor is a compact laser vision sensor designed for robotic weld seam positioning and real-time tracking. It is suitable for medium- and close-range welding applications involving small grooves, narrow gaps and other workpieces requiring precise seam detection.

The sensor provides a maximum frame rate of 110 Hz and supports TCP, Modbus TCP, UDP and EtherNet/IP communication protocols. It can be integrated with robotic welding units and automated welding systems through standard industrial communication interfaces.

Applications

  • Robotic weld seam positioning
  • Real-time weld seam tracking
  • Small groove welding
  • Narrow gap welding
  • Medium- and close-range weld seam detection
  • Collaborative robotic welding units

Product Features

  • Designed for medium- and close-range welding applications
  • Suitable for small grooves and narrow gaps
  • Supports real-time seam positioning and tracking
  • Maximum frame rate of 110 Hz
  • Compact and highly integrated structure
  • Supports multiple industrial communication protocols
  • Supports air cooling and water cooling
  • Operating temperature range from -10°C to 60°C

Main Technical Data

ParameterSpecification
Product ModelCP160V
Maximum Frame Rate110 Hz
Central Working Distance160 mm
Z-Axis Detection Range80–240 mm
Y-Axis Detection Range55–130 mm
Z-Axis Resolution0.10–0.55 mm
Y-Axis Resolution0.06–0.13 mm
Minimum Recognition Height0.30 mm
Minimum Recognition Width0.50 mm
Welding Speed50 mm/s
Communication ProtocolsTCP, Modbus TCP, UDP and EtherNet/IP
Maximum Operating Power6 W
Operating Voltage24 V
Operating Temperature-10°C to 60°C
Laser Class3B
Dimensions93 × 67 × 33 mm
Weight323 g
Cooling MethodAir cooling or water cooling
